板装插座 3.96mm 插件 180° 7位(6T)
FWF39601-S07S24W5B
Wafer 3.96mm 180°Vertical 7Circuits(DIP)
FWF39601-S07S24W5B Copy
Share this product
Stock(pcs)
4742
Lead time

≦ 4742 In stock

＞ 4742 Estimated delivery date 2025-12-29

MPQ
1000
MOQ
1000
Quantity Unit Price
1 $0.196136
10 $0.156492
50 $0.135626
100 $0.129366
500 $0.108501
1000 $0.075951
5000 $0.074281
10000 $0.073447

Standard Packaging Recommendations

The type of packaging (e.g., tape and reel, tube, pallet) may vary when products are purchased in quantities less than the standard packaging.

Category
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3.96mm
Row Option
Single row
Number of Positions
7Circuits
Orientation
Vertical(180°)
Colour
Natural
Electrical
Current(Max)
7A
Voltage(Max)
250V
Contact Resistance
20 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-40ºC~+85ºC
Mechanical
Mounting Style
Through hole
Material
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA6T
Flammability Rating
UL94 V-0
Packaging
Packaging
PE Bag

Product Drawings

Drawing-FWF39601

Product Specifications

FWF39601Productspecification.pdf
Plug
Wire to board housing 3.96mm 7Circuits

FHG39601-S07M2W1B

Wire to board housing 3.96mm 7Circuits
