FWF39614-S07S25W5M
板装插座 3.96mm 立贴 7位
Wafer 3.96mm 180°Vertical 7Circuits (SMT)
Product Number：FWF39614-S07S25W5M
Production Status： Active
Wafer 3.96mm 180°Vertical 7Circuits (SMT)
The pictures are for reference only for installation methods, please refer to the specifications and drawings for details
Product Catalog
Connectors
Product System
Wire to Board/Wire Connector
Style
Socket
Gender
Female
Pitch
3.96mm
Row Option
Single row
Number of Positions
7Circuits
Orientation
Vertical(180°)
Colour
Natural
Current(Max)
7A
Voltage(Max)
250V
Contact Resistance
20 mΩ Max
Insulation Resistance
1000 MΩ Min
Withstanding Voltage
1500V AC r.m.s
Operating Temperature Range
-25ºC~+85ºC
Mounting Style
SMT
Material-Contact
Brass
Plating
Bright tin plated
Material-Resin
PA9T
Flammability Rating
UL94 V-0
Packaging
Reel

Product Drawings

FWF39614 Series.pdf
REACH (EU REACH Regulation) Does not contain REACH SVHC (1907/2006/EC)
ROHS (EU ROHS Directive) Complies with EU Restriction of Hazardous Substances Directive 2011/65/EU (RoHS2)
ELV (EU ELV Directive) Complies with End-of-Life Vehicles Directive 2000/53/EC (ELV) substance restriction requirements
Plug
Wire to board housing 3.96mm 7Circuits
FHG39601-S07M2W1B
Wire to board housing 3.96mm 7Circuits
